Melling 10295 Chevy Gm Ls Ls1 Ls2 Ls3 High Pressure Performance Oil

Melling 10295 High Performance Oil Pump

Engine Oil Pump

SPECIFICATIONS:

• Additional Pressure Over Stock Percentage: 10 PSI
• Adjustable Bypass Pressure: Yes
• Alternate Pressure Springs Included: Yes
• Drive Type: Crankshaft
• Gasket Or Seal Included: Yes
• Grade Type: Performance
• Height: 4.45 IN
• Height: 116.0 MM
• Housing Finish: Anodized Hardcoat
• Housing Material: Cast Aluminum
• Mounting Hole Diameter: 8.86 MM
• Mounting Hole Diameter: 0.34 IN
• Mounting Hole Quantity: 4
• Oil Pump Pressure Type: High Pressure
• Oil Pump Type: Rotary
• Oil Pump Volume Type: Standard Volume
• Pick Up Tube Diameter: 0.875 IN
• Pick Up Tube Diameter: 22.225 MM
• Width: 8.0 IN
• Width: 204.0 MM

This item may interchange to the following part numbers from other brands. This is provided for reference only and does not guarantee that the part your are buying is identical to the part numbers from the brands listed below. To confirm that this part fits your vehicle, enter your vehicles Year, Make, Model, Trim and Engine in the Compatibility Table.

• Melling Select Performance 10295

Melling high performance oil pumps provide dependable performance every time in every application under the toughest RPM conditions. The Melling 10295 high performance oil pump is a high pressure, standard volume upgrade of the M295. The cast aluminum housing is CNC machined and hardcoat anodized. The cast iron cover is CNC machined and phosphate coated for improved pump performance and durability. The relief valve features a screw in valve plug with the optional lower stock pressure spring supplied. The oil pump and screen seals are included. Every Melling high performance oil pump is individually tested for pressure and flow under actual engine operating conditions.

Additional Specifications:

Grade Type: Performance

Height (MM): 116.0

Housing Finish: Anodized Hardcoat

Mounting Hole Diameter (IN): 0.34

Mounting Hole Quantity: 4

Mounting Hole Diameter (MM): 8.86

Gasket Or Seal Included: Yes

Drive Type: Crankshaft

Pick Up Tube Diameter (MM): 22.225

Pick Up Tube Diameter (IN): 0.875

Height (IN): 4.45

Housing Material: Cast Aluminum

Adjustable Bypass Pressure: Yes
